Tungsten Carbide Cylindrical Rotary Burrs for Metal

SKU
A
Product Details
  • Application areas encompass machining cast iron, cast steel, carbon steel, alloy steel, stainless steel, hardened steel, copper and aluminium
  • DIN: ZYA
  • Type of cut: F = Fine, M = Medium, C = Coarse
  • X-Cut: for hard and soft materials, produces short and blunt chips, runs smoothly even at low cutting speeds
  • Diamond cut: for heat-treated and tough alloy steels and epoxy, excellent finish, minimal axial forces
  • End cut: cylindrical burrs (A) and inverted cone burrs (N) can be supplied with end cut
  • Stock standard: X = yes
  • Deburring of edges and plane surfaces
  • Indispensable tool, used in large number of industrial sectors including aviation, shipping, automotive and the chemical industry etc.
  • Used to deburr irregular objects or to complete finishing work inside a confined space
  • Number of teeth is also indicated in addition to the type of cut for each rotary burr
Technical Details
グループ製品アイテム
商品 インターネットで買う
A1625M06XE 16 mm 25 mm 6 mm 65 mm M* 28/14 70 g
A0616M06DE 6 mm 16 mm 6 mm 50 mm M* 16/16 20 g
A1625M08X 16 mm 25 mm 8 mm 65 mm M 28/14 x 70 g
A0820F06 8 mm 20 mm 6 mm 60 mm F 28 30 g
A0820M06XE 8 mm 20 mm 6 mm 60 mm M 18/9 x 30 g
A1020M06X 10 mm 20 mm 6 mm 60 mm M 20/10 x 30 g
A0313F03 3 mm 13 mm 3 mm 40 mm F 18 x 10 g
A1225M06X 12 mm 25 mm 6 mm 65 mm M 24/12 x 50 g
A1225F06 12 mm 25 mm 6 mm 65 mm F* 36 50 g
A0313M03XE 3 mm 13 mm 3 mm 40 mm M XE 14/7 x 10 g
A1225M08E 12 mm 25 mm 8 mm 65 mm M* 24 55 g
A0616F06 6 mm 16 mm 6 mm 50 mm F 24 x 20 g
A1625M06 16 mm 25 mm 6 mm 65 mm M* 28 70 g
A1625M08 16 mm 25 mm 8 mm 65 mm M 28 x 70 g
A0616M06XE 6 mm 16 mm 6 mm 50 mm M 16/8 x 20 g
A0820M06E 8 mm 20 mm 6 mm 60 mm M* 18 30 g
A1020M06 10 mm 20 mm 6 mm 60 mm M 20 x 30 g
A1040M06X 10 mm 40 mm 6 mm 60 mm x 20/10 55 g
A0313M03E 3 mm 13 mm 3 mm 40 mm M* 14 10 g
A1225F08 12 mm 25 mm 8 mm 65 mm F* 36 55 g
A1225M06DE 12 mm 25 mm 6 mm 65 mm M* 24/24 50 g
A0313C03 3 mm 13 mm 3 mm 40 mm C 14 x 10 g
A1225C08 12 mm 25 mm 8 mm 65 mm C* 16 55 g
A1625C06 16 mm 25 mm 6 mm 65 mm C* 18 70 g
A0616M06E 6 mm 16 mm 6 mm 50 mm M 18 x 20 g
A1625M08XE 16 mm 25 mm 8 mm 65 mm M 28/14 x 70 g
A0820F06E 8 mm 20 mm 6 mm 60 mm F* 28 30 g
A0820C06 8 mm 20 mm 6 mm 60 mm C* 12 30 g
A1020M06XE 10 mm 20 mm 6 mm 60 mm M 20/10 x 30 g
A0313F03E 3 mm 13 mm 3 mm 40 mm F* 18 10 g
A1225M06XE 12 mm 25 mm 6 mm 65 mm M 24/12 x 50 g
A1225F06E 12 mm 25 mm 6 mm 65 mm F* 36 50 g
A0313M03XE-60 3 mm 13 mm 3 mm 60 mm M* 14/7 15 g
A1225M08X 12 mm 25 mm 8 mm 65 mm M* 24 55 g
A1625M06X 16 mm 25 mm 6 mm 65 mm M 28 x 70 g
A0616M06 6 mm 16 mm 6 mm 50 mm M 16 x 20 g
A1625M08E 16 mm 25 mm 8 mm 65 mm M* 28 70 g
A0616C06 6 mm 16 mm 6 mm 50 mm C 10 x 20 g
A0820M06X 8 mm 20 mm 6 mm 60 mm M 18/9 x 30 g
A1020M06E 10 mm 20 mm 6 mm 60 mm M* 20 30 g
A1050M06X 10 mm 50 mm 6 mm 90 mm x* 20/10 65 g
A0313M03X 3 mm 13 mm 3 mm 40 mm M 14/7 x 10 g
A1225M08 12 mm 25 mm 8 mm 65 mm M 24 x 55 g
A1225M06E 12 mm 25 mm 6 mm 65 mm M* 24 50 g
A0613M03X 6 mm 13 mm 3 mm 48 mm M X 16/8 x 15 g
A1625F06 16 mm 25 mm 6 mm 65 mm F* 40 70 g
A1625F08 16 mm 25 mm 8 mm 65 mm F* 40 70 g
A0616M06X 6 mm 16 mm 6 mm 50 mm M 16/8 x 20 g
A1625C08 16 mm 25 mm 8 mm 65 mm C* 18 70 g
A0820M06 8 mm 20 mm 6 mm 60 mm M 18 x 30 g
A1020F06 10 mm 20 mm 6 mm 60 mm F* 32 30 g
A1020C06 10 mm 20 mm 6 mm 60 mm C* 14 30 g
A0313M03 3 mm 13 mm 3 mm 40 mm M 14 x 10 g
A1225C06 12 mm 25 mm 6 mm 65 mm C 16 x 50 g
A1225M06 12 mm 25 mm 6 mm 65 mm M 24 x 50 g
A0313M03XE-80 3 mm 13 mm 3 mm 80 mm M 14/7 x 15 g
A1225M08XE 12 mm 25 mm 8 mm 65 mm M* 24/12 55 g
