Non-Sparking Mechanical Adjustable Torque Click Wrenches with Window Scale and Fixed Ratchet Head in Aluminium Bronze

SKU

NS041

Buy online Buy local

Product Details

Made of aluminium bronze
Large dual scale in N.m/ft.lb
Reversible ratchet head allowing clockwise operation only
Micrometer and main scale for adjustment
Sturdy plastic handle with a nice positive lock which engages or disengages clearly
Good positive audible engagement and the wrench always returns to home after each test
Accurate to ±6% of reading
Ratchet with 24-45 teeth and easy-change direction lever on top of the head
Supplied with a declaration of conformity traceable to international standards
All in individual rigid case for maximum protection and storage
Non-sparking (NS) tools designed for use in potentially explosive environments, where conventional steel tools may produce sparks

Documents

Manuals

Certificates

Exploded View

Add to Wish List Send a Request

Technical Details

Grouped product items
Product
Non-Sparking Mechanical Adjustable Torque Click Wrenches with Window Scale and Fixed Ratchet Head in Aluminium Bronze 8 N.m-25 N.m NS041-8-25	5-25 N·m	3.75-18.75 lbf·ft	1/4"	290 mm	277 mm	214 mm	27 mm	14 mm	20,5 mm	0.41 kg
Non-Sparking Mechanical Adjustable Torque Click Wrenches with Window Scale and Fixed Ratchet Head in Aluminium Bronze 12 N.m-50 N.m NS041-12-50	10-50 N·m	7.5-37.5 lbf·ft	3/8''	360 mm	340 mm	270 mm	40 mm	33 mm	22,5 mm	0.93 kg
Non-Sparking Mechanical Adjustable Torque Click Wrenches with Window Scale and Fixed Ratchet Head in Aluminium Bronze 16 N.m-100 N.m NS041-16-100	20-100 N·m	15-75 lbf·ft	1/2''	405 mm	385 mm	315 mm	40 mm	37 mm	22 mm	1.03 kg
Non-Sparking Mechanical Adjustable Torque Click Wrenches with Window Scale and Fixed Ratchet Head in Aluminium Bronze 16 N.m-200 N.m NS041-16-200	40-200 N·m	30-150 lbf·ft	1/2''	500 mm	480 mm	410 mm	40 mm	37 mm	22 mm	1.22 kg
Non-Sparking Mechanical Adjustable Torque Click Wrenches with Window Scale and Fixed Ratchet Head in Aluminium Bronze 16 N.m-260 N.m NS041-16-260	60-260 N·m	45-195 lbf·ft	1/2''	595 mm	575 mm	505 mm	40 mm	37 mm	22 mm	1.42 kg
Non-Sparking Mechanical Adjustable Torque Click Wrenches with Window Scale and Fixed Ratchet Head in Aluminium Bronze 24 N.m-670 N.m NS041-24-670	150-670 N·m	110-500 lbf·ft	3/4"	1150 mm	1139 mm	1069 mm	63 mm	56 mm	33,5 mm	5.62 kg
Non-Sparking Mechanical Adjustable Torque Click Wrenches with Window Scale and Fixed Ratchet Head in Aluminium Bronze 32 N.m-900 N.m NS041-32-900	200-900 N·m	150-675 lbf·ft	1"	1245 mm	1234 mm	1164 mm	63 mm	61 mm	33,5 mm	7.13 kg
