Mechanical Adjustable Window Scale Breaking Torque Wrench with Fixed Ratchet Head

Product Details
  • When reaching the target torque the wrench seems to 'break' in the middle which drastically reduces the risk of over-torque
  • Dual scale in N·m/
  • Range covering from 120 to 1,000 N·m/100 to 750 torque values
  • Can be used clockwise or anticlockwise by pushing across the square drive of the ratchet head
  • Accurate to ±4% of reading
  • Breaking system triggers a visual and tactile signal
  • Push-through ratchet heads allowing CW and ACW operation
  • Delivered in two parts for when storage space is limited such as vehicle tool kits
  • Scale is visible and protected by a window on the handle
  • All in a portable sturdy blow mould case
  • All wrenches come with a factory declaration of conformity according to ISO 6789-1:2017
  • Made in the UK
Technical Details
Break-Back Wider Angle Clockwiswe Accuracy 4% Anticlockwiswe Accuracy 4% Stop Applying Toque Visual Feedback Dual Scale Fixed Push-Through Ratchet Head Portable Mould Case Declaration Conformity
Grouped product items
Product Buy online
3/4" Square Drive Mechanical Adjustable Torque Breaking Wrench 200 N.m-800 N.m 76R3-800 200-800 N·m 150-600 lbf·ft 3/4-1 in 10 N·m 10 lbf·ft 1214 mm 1180 mm 1089 mm 69 mm 75 mm 738 mm 35 mm 105 mm 38 mm 7.300 kg
