Mechanical Adjustable Torque Click Wrench with Window Scale and Fixed Push-Through Ratchet Head

SKU

74WR-50/74WR-400

Product Details

Durable, reliable and accurate mechanism
Fast scale adjustment reducing the effort required to adjust
Large dual scale in N·m/ft.lb
Range covering from 10 and 400 N·m/7.5 - 300 ft.lb torque values
Can be used clockwise or anticlockwise by pushing across the square drive of the ratchet head
Accurate to ±3% of reading which exceeds the requirements of ISO6789-1:2017
Clicking system triggers a tactile and audible signal
Push-through ratchet heads from 3/8" to 3/4" square drives allowing CW and ACW operations
Handle centre or calibration force point marked on handle
Lock/unlock knob with blue ring inside to warn the operator the wrench is unlocked
In a semi-transparent square tube with eurohole hanger
All wrenches come with a factory calibration certificate according to ISO 6789-2:2017
Made in the UK

Documents

Manuals

Exploded View

Technical Details

Grouped product items
Product
1/2" Square Drive Mechanical Adjustable Window Torque Click Wrench 20 N.m-100 N.m 74WR-100	20-100 N·m	15-75 lbf·ft	1/2"	1 N·m	1 lbf·ft	387 mm	364 mm	278 mm	45 mm	48 mm	32 mm	0.9 kg
1/2" Square Drive Mechanical Adjustable Window Torque Click Wrench 40 N.m-200 N.m 74WR-200	40-200 N·m	30-150 lbf·ft	1/2"	2 N·m	2 lbf·ft	470 mm	447 mm	361 mm	45 mm	48 mm	32 mm	1.1 kg
1/2" Square Drive Mechanical Adjustable Window Torque Click Wrench 60 N.m-340 N.m 74WR-340	60-340 N·m	45-250 lbf·ft	1/2"	5 N·m	2 lbf·ft	685 mm	659 mm	572 mm	52 mm	48 mm	33 mm	1.5 kg
1/2" Square Drive Mechanical Adjustable Window Torque Click Wrench 80 N.m-400 N.m 74WR-400	80-400 N·m	60-300 lbf·ft	3/4"	5 N·m	5 lbf·ft	686 mm	661 mm	574 mm	51 mm	47 mm	24 mm	1.9 kg
